WiLLstudio™ GVX Pendant

Architectural Pendant Lighting

Flexible decorative lighting for outdoor architectural applications.

Request a Quote

Document Downloads

Specification Sheet (.pdf) IES Files (.zip)

Made in America

Quality Craftsmanship. Reputable Service + Support.

Multiple Mounting Options

Made to order custom mounting brackets / arms for retrofit or new installs.

Architectural Finish Coatings

Textured powder coat, anodizing, and custom color matching of RAL codes and architectural colors.

GVX Pendant Light - Dimensions

GVX Pendant

Housing Size:
20"

----

Lumen Range:
6,000 - 22,000

----

Wattage:
45W - 180W

----

Applications:
Area / Site

Made-to-Order //
Flexible Specs

Custom fixtures built to your specs – from finish color and LED color temp to lighting distribution, voltage, mounting, and more.

Custom-Made
Brackets & Arms

Made-to-order custom mounting brackets / arms for retrofit or new installs.

Learn More
WiLLstudio GVX Pendant LED Light Fixture
WiLLstudio GVX Pendant LED Light Fixture with custom arm mount
WiLLstudio GVX Pendant LED Light Fixture with mast arm mount
WiLLstudio GVX Pendant LED Light Fixture with decorative shepherds hook mount arm
WiLLstudio GVX Pendant LED Light Fixture with decorative bracket arm
WiLLstudio GVX Pendant LED Light Fixture with dual decorative bracket arm
WiLLstudio GVX Pendant LED Light Fixture with custom finish
WiLLstudio GVX Pendant LED Light Fixture with dual shepherds hook arm
WiLLstudio GVX Pendant LED Light Fixture
WiLLstudio GVX Pendant LED Light Fixture with custom arm mount
WiLLstudio GVX Pendant LED Light Fixture with mast arm mount
WiLLstudio GVX Pendant LED Light Fixture with decorative shepherds hook mount arm
WiLLstudio GVX Pendant LED Light Fixture with decorative bracket arm
WiLLstudio GVX Pendant LED Light Fixture with dual decorative bracket arm
WiLLstudio GVX Pendant LED Light Fixture with custom finish
WiLLstudio GVX Pendant LED Light Fixture with dual shepherds hook arm

WiLLstudio™ GVX Pendant

Specification Sheet (.pdf) IES Files (.zip)
  • For Immediate Support & Current Lead Times, Call 866-308-9455.

CONFIGURE YOUR GVX FIXTURE

Warranty & Terms

WiLL Limited Product Warranty (.pdf)
WiLL Terms & Conditions of Sale (.pdf)
WiLL Anodizing Advisory (.pdf)

Product Guides

WiLL Anchor Bolt Install Guide (.pdf)
WiLL Light Pole Maintenance Guide (.pdf)
WiLL LED Lighting Maintenance Guide (.pdf)

Wind Maps

1994 AASHTO Wind Map (.pdf)
2009 AASHTO Wind Map (.pdf)
2010 FL Code 180 MPH Wind Map (.pdf)

High Wind

RSAA Ultimate 3 Second Gust Wind Ratings (.pdf)
SSAA Ultimate 3 Second Gust Wind Ratings (.pdf)
RTA AASHTO/FBC 2010 High Wind Ratings (8-25 ft.) (.pdf)
RTA AASHTO/FBC 2010 High Wind Ratings (20-50 ft.) (.pdf)

Part Number Matrix

EX: WD-GVX-80-30-MV-5W-BK-PM-SRG27710

Product Family Design Performance
(Watts = Nominal Lumens)		 Color Temp Voltage Distribution Finish Color
WD = WiLLstudio™ GVX = Medium Housing 40 = 6,000 30 = 3000K, 70 CRI MV = 120-277V 1S = Type I Short BK = Black (Standard)
CH = Custom 80 = 12,000 40 = 4000K, 70 CRI HV = 277-480V 2M = Type II Medium BZ = Bronze
115 = 18,000 50 = 5000K, 70 CRI CV = Custom 3M = Type III Medium WH = White
155 = 22,000 PCA = PC Amber (590 nm) 3W = Type III Wide NA = Nat Alum Silver
CW = Custom & Amber TA = True Amber (593 nm) 4M = Type IV Medium LG = Light Gray
CT = Custom 5W = 150° Type V Square SG = Slate Gray
  5M = 90° Type V Medium DG = Dark Green
5N = 70° Type V Narrow DP = Dark Platinum
CL = Clear Lens GM = Graphite Metallic
DL = Frosted Lens RAL = Custom RAL Match
CD = Custom

Options & Accessories

Mounting Arm Option Option Accessories
PM = Pendant Mount SH1 = Single Shepherds Hook CF1 = Center Shepherds Hook Decorative Feature WHP3NP = 2' Cord w/o Plug, Stripped Pigtail HSS-GVX = House Side Shield
CM = Custom SH2 = Single Side Shepherds Hook CF2 = Center Shepherds Hook Brand/Logo/City Round Feature WHP7NP = 6' Cord w/o Plug, Stripped Pigtail WM-GVX = Side Mount Wall Bracket
SH3 = 2@180 Side Shepherds Hook CF = Custom WHP11NP = 10' Cord w/o Plug, Stripped Pigtail GFX = Wireless DMX Lighting Control System (Consult Factory)
AR1 = Single Suspension Arm SRG27710 = 10kA Surge Suppressor (Field Replaceable), 120-277V GFM = Wireless Mesh Lighting Control System (Consult Factory)
AR2 = 2@180 Suspension Arm SRG48010 = 10kA Surge Suppressor (Field Replaceable), 347-480V
AR3 = Short Hub Mast Arm w/ Gusset BPC1 = Button Photocontrol, 120-277V
AR4 = Medium Hub Mast Arm w/ Gusset BPC3 = Button Photocontrol, 347V
AR5 = Short Upsweep Arm No Gusset BPC4 = Button Photocontrol, 480V
AR6 = 2@180 Upsweep Arm No Gusset MPS = Programmable Motion Sensor w/ ON/OFF + Dimming + Photocontrol, Bluetooth Settings Adjustable, maximum coverage of 100' diameter from 40' mounting height
CA = Custom

Note: Custom products, configurations, options, and accessories available from factory.
